A Comparative Study of Chronic Obstructive Pulmonary Disease Rat Models Established by Different Methods

doi:10.12300/j.issn.1674-5817.2021.118

Abstract

Abstract:

Objective To compare the effects and characteristics of cigarette smoke exposure (CSE) alone and CSE combined with airway instillation of bacterial lipopolysaccharide (LPS) in chronic obstructive pulmonary disease (COPD).Methods Male SD rats were randomly divided into control, CSE, and CSE+LPS groups, with 10 rats in each group. After 24 weeks, the models were established and the lung function of the rats was measured. Hematoxylin-eosin (HE) staining was performed to observe the pathological changes in the airway and lung tissue. The ELISA method was used to detect the level of serum interleukin-8 (IL-8) and tumor necrosis factor α (TNF-α) in peripheral blood.Results Airway resistance (RI), functional residual capacity (FRC), and chord compliance (Cchord) of the CSE and LPS+CSE groups were higher than those of the control group (all P < 0.05), while the tidal volume (TV), minute volume (MV), and forced expiratory volume in 50 ms (FEV50) / forced vital capacity (FVC) of the CSE and LPS+CSE groups were lower than those of the control group (all P < 0.05). HE staining of lung tissue showed that the average alveolar intercept and thickness of the small airway walls were higher in the CSE and LPS+CSE groups than those in the control group. Compensatory enlargement was evident in the alveolar cavity of the CSE and CSE+LPS groups, and the alveolar septum widened, with a fusion of pulmonary alveoli in the CSE+LPS group. The levels of IL-8 and TNF-α in serum of the CSE and CSE+LPS groups were higher than those of the control group (all P < 0.05). The level of TNF-α in serum of the CSE+LPS group was higher than that of the CSE group (P < 0.05).Conclusion The CSE combined with LPS method is superior to CSE alone for establishing the COPD rat model, and the combined model is closer to clinical manifestations.

Key words: Chronic obstructive pulmonary disease, Lipopolysaccharide, Cigarette smoke, Lung function, Rat models

CLC Number:

Q95-33

Xinpeng LU, Rong LIU, Wenbo Huang, Jin ZHAO, Hongtao LI. A Comparative Study of Chronic Obstructive Pulmonary Disease Rat Models Established by Different Methods[J]. Laboratory Animal and Comparative Medicine, 2022, 42(3): 201-206.

Figures/Tables 5

Figure 1 Body weight growth curve of rats in each group after modelingNote： Control， rats in the control group raised in a normal environment； CSE， rats in the cigarette smoke exposure group； CSE+LPS， rats in the intratracheal LPS instillation combined with CSE group. There were 10 rats in each group.

Table 1 Lung functions of rats in each group after modeling

Group	RI/(cmH₂O·s^－1·mL^－1)	TV/mL	Cchord/(mL·cmH₂O^－1)	FRC/mL	MV/mL	FEV50/ (FVC/%)
Control	0.250±0.026	3.90±0.19	1.210±0.042	5.29±0.51	233.98±11.40	0.155±0.041
CSE	0.315±0.018^*	3.64±0.10^*	1.310±0.071^*	5.88±0.59^*	218.72±5.18	0.118±0.030^*
CSE+LPS	0.348±0.025^*#	3.57±0.14^*	1.395±0.120^*	6.58±0.44^*#	214.12±8.60^*	0.099±0.035^*#

Figure 2 Pathological changes of lung tissues of rats in each group （HE staining， ×100）Note： Control， rats in the control group raised in a normal environment； CSE， rats in the cigarette smoke exposure group； CSE+LPS， rats in the intratracheal LPS instillation combined with CSE group.

Table 2 Serum contents of IL-8 and TNF-ɑ in different groups of rats

CSE

CSE+LPS

162.87±17.95^*

160.72±33.04^*

109.35±13.78^*

141.10±18.82^*#

References 18

1	World Health Organization. Projection of mortality and cause of death, 2016 to 2060 [EB/OL]. [2019-10-14]. .
2	WANG C, XU J Y, YANG L, et al. Prevalence and risk factors of chronic obstructive pulmonary disease in China (the China Pulmonary Health[CPH]study): a national cross-sectional study[J]. Lancet, 2018, 391(10131):1706-1717. DOI:10.1016/S0140-6736(18)30841-9 .
3	李征途, 徐小明, 巩雪芳, 等. 应用熏烟联合脂多糖方法建立慢性阻塞性肺疾病相关肺动脉高压小鼠模型[J]. 国际呼吸杂志, 2014, 34(1):27-30, 封3.
	LI Z T, XU X M, GONG X F, et al. Cigarette smoking plus airway LPS inhalation induced COPD-PAH in mouse[J]. Int J Respir, 2014, 34 (1):27-30. DOI:10.3760/cma.j.issn.1673-436X.2014.01.005 .
4	LI D F, WANG J, SUN D J, et al. Tanshinone IIA sulfonate protects against cigarette smoke-induced COPD and down-regulation of CFTR in mice[J]. Sci Rep, 2018, 8(1):376. DOI:10.1038/s41598-017-18745-5 .
5	LU W J, LI D F, HU J Y, et al. Hydrogen gas inhalation protects against cigarette smoke-induced COPD development in mice[J]. J Thorac Dis, 2018, 10(6):3232-3243. DOI:10.21037/jtd.2018. 05.93 .
6	LI Y, LI S Y, LI J S, et al. A rat model for stable chronic obstructive pulmonary disease induced by cigarette smoke inhalation and repetitive bacterial infection[J]. Biol Pharm Bull, 2012, 35(10):1752-1760. DOI:10.1248/bpb.b12-00407 .
7	周凤, 李德富, 袁良, 等. 两种不同方法建立的小鼠慢性阻塞性肺疾病模型的比较研究[J]. 中华结核和呼吸杂志, 2019, 42(5):367-371.
	ZHOU F, LI D F, YUAN L, et, al. A comparative study of two thronic obstructive pulmonary disease mouse models established by different methods[J]. Chin J Tuberc Respir Dis, 2019, 42(5):367-371. DOI:10.3760/cma.j.issn.1001-0939.2019.05.010 .
8	SHU J Z, LI D F, OUYANG H P, et al. Comparison and evaluation of two different methods to establish the cigarette smoke exposure mouse model of COPD[J]. Sci Rep, 2017, 7(1):15454. DOI:10.1038/s41598-017-15685-y .
9	WRIGHT J L, CHURG A. A model of tobacco smoke-induced airflow obstruction in the Guinea pig[J]. Chest, 2002, 121(5 Suppl):188S-191S. DOI:10.1378/chest.121.5_suppl.188s .
10	LIU X Y, MA C Q, WANG X Y, et al. Hydrogen coadministration slows the development of COPD-like lung disease in a cigarette smoke-induced rat model[J]. Int J Chron Obstruct Pulmon Dis, 2017, 12:1309-1324. DOI:10.2147/COPD.S124547 .
11	HE F, LIAO B L, PU J D, et al. Exposure to ambient particulate matter induced COPD in a rat model and a description of the underlying mechanism[J]. Sci Rep, 2017, 7:45666. DOI:10.1038/srep45666 .
12	王光艳, 刘菁, 刘学东. 烟熏PM_2.5颗粒建立COPD大鼠模型[J]. 国际呼吸杂志, 2017, 37(21):1610-1613. DOI:10.3760/cma.j.issn.1673-436X.2017.21.002 .
	WANG G Y, LIU J, LIU X D. Rat model of COPD established by inhalation with PM_2.5 [J]. Int J Respir, 2017, 37(21):1610-1613. DOI:10.3760/cma.j.issn.1673-436X.2017.21.002 .
13	VERNOOY J H J, DENTENER M A, VAN SUYLEN R J, et al. Long-term intratracheal lipopolysaccharide exposure in mice results in chronic lung inflammation and persistent pathology[J]. Am J Respir Cell Mol Biol, 2002, 26(1):152-159. DOI:10.1165/ajrcmb.26.1.4652 .
14	HU Y X, CUI H, FAN L, et al. Resveratrol attenuates left ventricular remodeling in old rats with COPD induced by cigarette smoke exposure and LPS instillation[J]. Can J Physiol Pharmacol, 2013, 91(12):1044-1054. DOI:10.1139/cjpp-2012-0464 .
15	庞宝森, 李远红, 张洪玉. 慢性阻塞性肺疾病动物模型的研究进展[J]. 心肺血管病杂志, 2005, 24(1):45-46. DOI:10.3969/j.issn.1007-5062.2005.01.016 .
	PANG B S, LI Y H, ZHANG H Y. Research progresseson animal models of emphysema[J]. Journal of Cardiovascular & Pulmonary Diseases, 2005, 24(1):45-46. DOI:10.3969/j.issn.1007-5062.2005.01.016 .
16	UNG T T, NGUYEN T T, LIAN S, et al. Nicotine stimulates IL-6 expression by activating the AP-1 and STAT-3 pathways in human endothelial EA.hy926 cells[J]. J Cell Biochem, 2019, 120(4):5531-5541. DOI:10.1002/jcb.27837 .
17	王妍, 朱虹江, 和春芳, 等. 清肺化痰颗粒对慢性阻塞性肺疾病急性加重期大鼠相关炎症因子及氧化应激反应的影响研究[J]. 现代中西医结合杂志, 2021, 30(12):1271-1276, 1281. DOI:10.3969/j.issn.1008-8849.2021.12.004 .
	WANG Y, ZHU H J, HE C F, et al. Effects of Qingfei Huatan granules on related inflammatory factors and oxidative stress reaction in rats with acute exacerbation of chronic obstructive pulmonary disease[J]. Modern Journal of Integrated Traditional Chinese and Western Medicine, 2021, 30(12): 1271-1276, 1281. DOI:10.3969/j.issn.1008-8849.2021.12.004 .
18	肖长栓, 刘娅平, 杨景哲. 雾化吸入和腹腔注射依达拉奉对烟雾吸入性损伤肺模型大鼠保护作用的比较研究[J]. 中国药房, 2021, 32(1):70-76. DOI:10.6039/j.issn.1001-0408.2021.01.13 .
	XIAO C S, LIU Y P, YANG J Z. Comparative study of protective effects of atomization inhalation and intra-peritoneal injection of edaravone on smoke inhalation lung injury model rats[J]. China Pharmacy, 2021, 32(1):70-76. DOI:10.6039/j.issn.1001-0408.2021.01.13 .
